The Powerline-5 Lithium Battery has a range of technical specifications that independently and collectively make it a superior choice for energy storage solutions. Here is a detailed look at each specification and its significance:
Nominal Voltage: 51.2V
The nominal voltage of 51.2V is ideal for compatibility with most solar power systems and inverters available on the market. This voltage level ensures that the battery can easily integrate into existing setups without needing additional equipment or significant modifications.
Nominal Capacity: 100Ah
A nominal capacity of 100Ah translates to substantial energy storage capability. Homeowners and businesses can store a significant amount of energy. This ensures a reliable power supply during periods of low solar generation or high energy demand. For instance, a 100Ah capacity can provide 5.12 kWh of energy, sufficient to power essential household appliances for several hours.
Compound Mode: 1P16S
The 1P16S configuration indicates that the battery has 16 cells connected in series. This setup enhances the battery’s overall voltage and power output, ensuring stable and reliable performance. The series connection helps to maintain consistent voltage levels necessary for the efficient operation of connected devices and systems.
Charging Voltage: 58.4V
The higher charging voltage of 58.4V allows for quicker recharge times. This maximises solar energy use by capturing more power during peak sunlight hours. This specifications means there’s reduced downtime and ensures the battery is always ready when needed.
Charge Current: Continuous Charging (50A), Maximum Charge (100A)
The Powerline-5 handles a continuous charging current of 50A and a maximum of 100A, significantly reducing recharge times. At 50A, a full charge takes roughly 2 hours, assuming a nominal capacity of 100Ah.
Discharge Current: Continuous Discharging (100A)
A continuous discharge current of 100A means the Powerline-5 can support high power demands without performance degradation. This is important for applications that require substantial energy output over a short period, such as powering multiple high-wattage appliances simultaneously or during peak consumption times.
Minimal Energy Loss (≤ 2.5% Monthly Self-Discharge Rate)
A low self-discharge rate of ≤ 2.5% per month ensures that the battery retains its charge over time, even during periods when it is inactive. For users who may not use the battery continuously, it ensures that stored energy is preserved and available when needed.
Mode of Equilibrium: Passive Equilibrium
Passive equilibrium refers to the battery’s ability to balance charge among its cells without active intervention. This improves the longevity and reliability of the battery, as it ensures uniform charge distribution and prevents individual cells from becoming overcharged or undercharged.
Temperature Range: Charge (0℃~65℃), Discharge (-20℃~65℃)
The PowerLine-5 operates effectively in a wide range of temperatures, from -20℃ to 65℃. It is suitable for various climates, from freezing winters to hot summers.
Space-Saving Design (Compact Dimensions)
The slim and compact design (670 x 540 x 90 mm ±1 mm) allows easy installation in limited spaces. Making the Powerline-5 ideal for residential solar setups where space might be a constraint.
How These Specifications Work Together
Independently, each specification of the Powerline-5 offers significant benefits. Collectively, they create a battery that is highly efficient, reliable, and versatile:
Efficiency: High charge and discharge currents combined with a low self-discharge rate ensure that the battery can quickly store and deliver energy with minimal losses.
Reliability: The nominal capacity and the stable voltage configuration, ensures consistent performance and longevity. This reduces the need for frequent replacements or maintenance.
Versatility: The wide temperature range and compact design make the Powerline-5 suitable for a variety of applications and environments, from residential to commercial setups, and in diverse climatic conditions.
The BSLBATT Powerline-5 Lithium Battery stands out as a superior energy storage solution due to its well-balanced technical specifications. Each feature contributes to making it an efficient, reliable, and versatile choice. The Powerline-5 is capable of meeting the demands of both residential and commercial users in South Africa and beyond.
